Structure
・Vehicle Category: L5M ・Seating Capacity: Driver + 3 Passengers ・Body Type: Metal Body ・Roof Type: Soft Top
Dimensions & Weight
・Overall Dimensions (L × W × H): 3010 × 1330 × 1825 mm ・Wheelbase: 2183 mm ・Minimum Ground Clearance: 200 mm ・Gross Vehicle Weight (GVW): 900 kg ・Kerb Weight: 400 kg ・Payload Capacity: 500 kg
Performance
・Top Speed: 42 km/h ・Gradeability: 20% ・Typical Driving Range: 150 km (Expected) ・Horse Power: 6 kW (Continuous) ・Peak Power: 11 kW ・Peak Torque: 90 Nm ・Regenerative Braking: Yes ・Motor Type: AC Induction Motor ・Steering Type: Handle Bar
Battery & Charging
・Battery Type: Lithium-Ion, 48V ・Battery Capacity: 9 kWh ・Charger Type: Off-board Charger (24V) ・Charging Time: 3.5 – 4 Hours
Suspension & Safety
・Front Suspension: Single Shock Absorber with Spring ・Rear Suspension: Trailing Arm, Rigid Axle with Helical Coil Spring and Shock Absorber ・Brakes (Front & Rear): Hydraulic Drum Brakes ・Hill Hold Assist: Yes ・Regenerative Braking: Yes ・Tyres: 4.50 × 10 (Low Rolling Resistance Tyres)
Comfort Features
・Instrument Cluster: 7” LCD Display ・Glove Box: Yes ・Mobile Charging: Yes ・Passenger Seat: With Folding Seat for cargo utility ・Color Options: As per your choice ・Head Lamps: LED ・Tail Lamps: LED ・Digital Instrument Cluster: Yes
Warranty & Service
Vehicle Warranty: 3 Years
